KMBC07-AC1UNV-P1K6-DC28-EN Power Supply and Battery Charger (1.6 kW)

• Single Phase Universal AC input
• Rugged Unit for Military Applications
• High Efficiency, High Power Density
• Wide Input Voltage Range
• Built-in Active PFC Function
• Charger for Lead-Acid Batteries (Flooded, GEL and AGM) and Li-Ion Batteries (Lithium Iron and Lithium Manganese)
• Internal OR-ing Diode
• Multiple Units in a Redundant or Parallel System
• IP67 Sealed
• RS485 Communication
• Temperature Sensor
• Power Good Signal
• Input Under Voltage Protection
• Input/Output Over Voltage Protection
• Input Over Current Protection
• Short Circuit Protection
• Over Temperature Protection
• Reverse Battery Protection
• Two unit can be mounted in 2U height 19″ Rack
• On/Off Switch
• LED Indicators
• Grounding Interface

Product Ratings

• V_IN: 90–265 V_RMS (single phase)
• V_{IN_NOM}: 220 V_RMS
• V_OUT:28.2 V_DC
• I_{OUT_MAX}:60 A_DC
• P_{OUT_MAX}:1692 W

Compliance
Module is designed to meet::

• MIL-STD-461G
• MIL-STD-810G
• MIL-STD-1275E

Dimensions

• 530.00 x 215.90 x 87.75 mm [19”/2 form factor, 2U height]
• Weight: 13 kg

Description

KMBC07 is a high efficiency AC-DC battery charger unit.

Typical Applications

• Military/Defense Power Systems
• Armored Vehicles
• Land Platforms
• Communications and Radar Systems

Manufacturer Info

• www.kolt.com.tr
