KMBM02-DC28-P300-DC28-QB – Isolated DC-DC Converter

• Operating Input Voltage Range 16 – 40 V
• Up to 300 W Output Power
• 92% Efficiency at Full Load Current
• Input Under Voltage Lockout
• Input/Output Over Voltage Protection
• Output Current Limit
• Short Circuit Protection
• Thermal Shutdown
• Remote ON/OFF Control
• Output Voltage Remote Sense
• Output Voltage Trim Range +10%*, -40%

*: Trim-up capability input voltage range 18-40VDC

Product Ratings

• V_IN: 16–40 V_DC
• V_{IN_NOM}: 28 V_DC
• V_OUT:28 V_DC
• I_{OUT_MAX}:10.7 A_DC
• P_{OUT_MAX}:300 W

Compliance
Converter (with an KRFL filter) is designed to meet:

• MIL-STD-461G
• MIL-STD-810G
• MIL-STD-1275E

Dimensions

• Size: 58.4 x 36.8 x 12.9 mm [2.3” x 1.45” x 0.51”]
• Weight: 80.1 g

Description

KMBM02-DC28-P300-DC28-QB is a 300 W DC/DC converter in quarter-brick size that operates from nominal 28 V input and generates 28 V isolated output.

Typical Applications

• Military/Defense Power Systems
• Armored Vehicles
• Land Platforms
• Aerospace Platforms
• Communications and Radar Systems
• Medical Systems

Manufacturer Info

• www.kolt.com.tr
