Non-Isolated DC-DC Converters Bucky Type, 1/16th Brick
- Non-isolated DC-DC 1/16th Brick Module
- Delivers power up to 300 W
- Rated for 60 A output current
- Peak efficiency 93.6%
- Input UVLO and OVLO protections
- Output over voltage protection
- Output overcurrent protection
- Output short-circuit protection
- Thermal Shutdown
- ON/OFF control
- Trim range +20%, -20%
- PMBUS pins are only present in PMBUS option
Ordering Information
- Family: KMNB01
- Input Voltage: 9-40 V
- Power: 100 W, 200 W, 300 W
- Output Voltage: 3.3 V, 5 V
- Package: Sixteenth Brick
- Options: PMBUS
Screening
- Full LOT traceability
- Burn-in at 100 °C baseplate temperature
- Temperature cycling
- Available with different screening grades
- Final visual inspection
Absolute Maximum Ratings
The absolute maximum ratings below are stress ratings only. Operation at or beyond these maximum ratings may cause permanent to the device.
- Operating Temperature: -40 to +100 °C
- Storage Temperature: -55 to +125 °C
Dimensions
- Size: 38 x 28 x 12.9 mm
Description
KMNB01 is a high power density product that solves your power regulation problems in applications where the lightweight and the small size are the most critical.
Designed to meet
with EMI filter module
- MIL-STD-461 (D, E, F, G)
- MIL-STD-704 (A-F)
- MIL-STD-1275 (D, E)
- MIL-STD-810
